| Specification |
|
| |
| - Termination to PCB : SMT reflow
soldering. |
| Peak service temperature
: 250℃ max |
| : 1 minute max |
| Temperature/time profile
according to CECC |
| 00 802 s6.1 figure
3. |
| - Level of each contact tail compared to the
|
| surrounding base of
the insultor. |
| Coplanarity of metal
soldering surfaces:0.1mm |
| - 2.0 microns tin-lead in solder tail areas. |
| - Contact forces : |
| max 0.5N/contact/0.7mm
contact deflection. |
| min 0.25N/contact/0.7mm
contact deflection. |
| - Precious metal inlay on signal contacts. |
| Durability > 1500
cycles. |
| Signal contact resistance
<100 mΩ |
| - Operating temperatue : -40 ℃ + 85 ℃ |
| - Locking force : 4N 2N. |
| Cover is easily changeable. |
| - For packaging on tape and reel, |
| see document cu F96000-0046 |
