| Specification |
|
| |
| ＝ SPECIFICATION |
| |
- Current Rating : 0.5 A |
| |
- Dielectric Withstanding Voltage : 540V
r.m.s |
| |
- Insulation Resistance : 100mз Min |
| |
- Contact Resistance : 100mз Min |
| |
- Operation Temperature : -10” to +70” |
|
| |
| ＝ MATERIAL |
|
|
- Contact : Beryllium Copper |
| |
- Insulator : LCP-30GF |
| |
- Finish : Gold Plated over Nickel |
|
|
| |
|
|
|
